HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration and Dust-Free Planetary Cutting

Brand Name : HUASHIDA

Model Number : Pre-Insulated Pipe Extrusion Line

Certification : CE, ISO9001:2008

Place of Origin : Qingdao, China

MOQ : 1

Price : US$200,000.00-1,000,000.00

Payment Terms : L/C,D/P,T/T

Supply Ability : 30 Sets/Year

Delivery Time : 60DAYS

Packaging Details : Standard Package

Calibration Method : Vacuum and Water Spraying Cooling

Cutting Method : Dust-Free Planetary Cutting

Raw Material : PE

Application : Producing Pre-Insulated Pipe Jacket

Contact Now

HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration

Product Description

The HDPE jacket casing pipe extrusion line is used for producing outer protective pipes for PU foam pre-insulated systems. Vacuum calibration ensures accurate sizing and excellent surface quality. PLC control enables stable, efficient, and energy-saving production for medium and large-scale output.
HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration and Dust-Free Planetary Cutting

Product Parameters

Style PE-110/500 PE-655/1380 PE-960/1860 PE-1155/2200
Main Extruder SJ-75/33 SJ-120/33 SJ-150/33 SJ-150/33
Pipe diameter Φ110-600mm Φ655-1380mm Φ960-1860mm Φ1155-2200mm
Capacity 250-350kg/h 700-900kg/h 1000-1200kg/h 1350kg/h
Installed power 160kw 480kw 580kw 650kw
Length 26m 36m 45m 45m

Production line composition:
-1set Vacuum loader
-1set Hopper dryer
-1set High-efficiency single screw extruder
-1set Vacuum calibration table
-1set Water spraying tank
-1set Hauling machine
-1set Cutting machine
-1set Discharging Frame
-1set PLC

Detailed Photos

Technical Highlights:
HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration and Dust-Free Planetary Cutting
Single-screw extruder
Proprietary single-screw extruder optimized for polyethylene (PE) materials
Precision temperature control system ensures consistent material fusion
HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration and Dust-Free Planetary Cutting
Vacuum Calibration
Vacuum calibration tank is mainly composed of frame, stainless steel tank, vacuum system, spray cooling system, position adjustment device. The vacuum pump exhausts the air from the sealed tank to pressurize the fresh pipe cling to calibrating copper sleeve and to calibrate the outer diameter. Spray nozzles spray cooling water from all directions on pipe surface to cool down the pipe promptly.
HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration and Dust-Free Planetary Cutting
Smart Automation
Fully integrated PLC control system
Real-time process monitoring
HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration and Dust-Free Planetary Cutting
Haul-off Machine
The haul-off machine is mainly composed of driving device, tracks, clamping structure, adjusting system, side plate and foundation bed. Haul-off tracks are driven by AC motor with frequency conversion control to adapt to different extrusion speeds.
An automatic length measuring device realizes cutting at a set length.
HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration and Dust-Free Planetary Cutting
No-Dust Cutter
It adopts blade punching principle to realize no-dust cutting. It is mainly composed of cutting device, clamping device, structure synchronous movement device and frame.

Our Advantages

Features of the HDPE sleeve production line:
1.small dimension
2.high degree of automation, can be operated by one person, saving labor costs
3.long service life.
4.high-efficiency extruder gives larger output, stable performance
5.pipe wall is average and smooth
6.no waste of raw material
7.One-time molding

The advantages of our company:
1.Provide a comprehensive and fully integrated production solution, including design, installation, commissioning, and training.
2.Share you 389 sets of production experience from all the world
3.Having 9 professional senior engineers
4.Having a high-end plastic machinery equipment expert workstation in China
HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration and Dust-Free Planetary Cutting
HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration and Dust-Free Planetary Cutting
HDPE Outer Jacket Pipe Extrusion Line for PU Pre-Insulated Pipe with Vacuum Calibration and Dust-Free Planetary Cutting

Qingdao Huashida Machinery Co., LTD., founded in 2003, is a global developer, manufacturer and solution provider of plastic extrusion equipment. 70% of its customers come from overseas countries such as Europe, America, the Middle East and Southeast Asia.
Welcome to our factory to discuss cooperation!
